Daikin JT1FDVDKTYR Inverter Scroll Compressor — 5HP VRV2 Series
The Daikin JT1FDVDKTYR is a high-efficiency inverter scroll compressor specifically engineered for Daikin VRV2 variable refrigerant volume air conditioning systems. Featuring Daikin’s advanced variable-frequency drive technology, this compressor delivers precise capacity modulation from low to full load, achieving superior energy efficiency and whisper-quiet operation — ideal for commercial buildings, hotels, and office spaces demanding both performance and comfort.
✅ Key Advantages
- Inverter Variable Frequency — Continuous capacity modulation, eliminating start-stop energy waste, up to 30% energy savings vs. fixed-speed compressors
- Daikin VRV2 Dedicated — Factory-matched for VRV2 R22 outdoor units (RHX12MAY1 series), plug-and-play replacement
- Advanced Scroll Technology — Asymmetric scroll profile for higher COP and lower vibration
- Ultra-Quiet Operation — Optimized for noise-sensitive environments: hotels, hospitals, premium offices
- Compact & Lightweight — Only 40 kg, significantly lighter than semi-hermetic alternatives of equivalent capacity
- Proven Reliability — Japan engineering, 15+ year design life under normal operating conditions
🔧 Applications
- Daikin VRV2 R22 series outdoor units (RHX12MAY1)
- Commercial central air conditioning systems
- Hotels, hospitals, and office building HVAC
- Multi-zone variable refrigerant systems
- Industrial process cooling (light-duty)
⚙️ Technical Features
- Compressor type: Hermetic inverter scroll
- Variable frequency range: 30–90 Hz (nominal 50 Hz)
- Refrigerant: R22
- Displacement: 53.9 cc/rev
- Tube connections: Suction Φ19.1 mm / Discharge Φ12.7 mm
- Mounting: 3-point base
- Maximum discharge temperature: 125°C
- Maximum motor winding temperature: 129.4°C
- Oil charge: 1.2 L (Daikin specified refrigeration oil)
AIWEI Refrigeration — Professional global exporter of Daikin compressors, 100% original products with quality guarantee and expert technical support.
📞 Contact Us
- WhatsApp: +86 180 7874 9441
- Email: qinxindong72@gmail.com
- Website: http://www.aiweirefrig.com
